Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley

Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley
Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley

Large Image :  Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley

Product Details:
Place of Origin: Henan China
Brand Name: Coil Rail Transfer Cart
Certification: CE ISO SGS
Model Number: Coil Rail Transfer Cart
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD:1000-6000/set
Packaging Details: Trap and Wooden Case
Delivery Time: 20 work days after received balance payment
Payment Terms: L/C, T/T
Supply Ability: 30sets/week
Detailed Product Description
Product Name: Industrial Large Motorized Transport Carts For Coils Transportation Welding Frame Aluminum Coil Transfer Trolley Running Speed(m/min): 0-15
Type: Coil Rail Transfer Cart Wheel Base(mm): 1200-7000
Ground Clearance(mm): 50 Rail Inner Gauge(mm): 1200-2000
Wheel Diameter(mm): 270-600 Table Size: Customized
High Light:

motorised rail trolley

,

motorized rail cart

Industrial Large Motorized Transport Carts for coils cargo transportation welding frame aluminum machine

Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley



The Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley is powered by cabled drum. The power source 380V alternating-current is supplied to the traction motor by cable. The Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley is widely used in the Aluminum Coil factory.



Advantage

  • Excellent gear reducer and motor with high quality, assemblied together perfectly
  • Safe devices are installed in the powered coil rail car
  • Remote control can be equipped together to operate the powered coil rail car well
  • Customization can be supported for the powered coil rail car
  • The kind of powered coil rail car is with large capacity and high quality
  • The kind of powered coil rail car can be applied in various occasions as high temperature, easy explosion, ponding, dust, scrap iron...
  • Added the hydraulic lifting device for your need
  • The V frame can be added for your nrequired
  • High requency use
  • No limitation of the running time
  • No limitation of the running distance
  • The powered coil rail car is no strict requirement for the rails
  • Custom v- or u shape
  • Low maintenance and repair cost
  • Suitable to working area with short running distance
  • Suitable to working area with high using frequency; Has no limit on running distance
  • Can be applied in high-temperature environment; Box girder structure
  • Reasonable design, reliable operation
  • Can be add hydraulic lifting device
  • Can be add dumping device; High efficiency, low energy consumption



Main Componences

Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley



Technical Table

Rated Load(t) 2 10 20 30 40 50 63 80 100 150
Wheel Base(mm) 1200 2600 2800 3200 3800 4200 4300 4700 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 1435 1435 1435 1435 1800 2000 2000
Wheel Quantity 4 4 4 4 4 4 4 4 4 4
Wheel Diameter(mm) Ø270 Ø300 Ø350 Ø400 Ø500 Ø500 Ø600 Ø600 Ø600 Ø600
Ground Clearance(mm) 50 50 50 50 50 50 75 75 75 75
Running Speed(m/min) 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-20 0-20 0-18
Motor Power(KN) 0.8 1.5 2.5 4 5.5 5.5 7.5 7.5 11 15
Max Wheel Load(KN) 14.4 42.6 77.7 110.4 142.8 174 221.4 278.4 343.8 265.2
Reference Weight(t) 2.3 3.8 5.5 77.7 110.4 142.8 174 221.4 278.4 343.8



The Scheme

Custom v- or u bracket



Application

Industrial Large Motorized Transport Carts for Coils Transportation Welding Frame Aluminum Coil Transfer Trolley
