Warehouse Station Use Trackless 300t Battery Powered Transfer Cart

Warehouse Station Use Trackless 300t Battery Powered Transfer Cart
Warehouse Station Use Trackless 300t Battery Powered Transfer Cart Warehouse Station Use Trackless 300t Battery Powered Transfer Cart Warehouse Station Use Trackless 300t Battery Powered Transfer Cart Warehouse Station Use Trackless 300t Battery Powered Transfer Cart

Large Image :  Warehouse Station Use Trackless 300t Battery Powered Transfer Cart

Product Details:
Place of Origin: China(Mainland)
Brand Name: battery drive platform transfer van
Certification: CE ISO SGS
Model Number: battery drive platform transfer van
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 3000~7000 set
Packaging Details: trap and wooden case
Delivery Time: 20 work days after received balance payment
Supply Ability: 100sets month
Detailed Product Description
Product Name: Battery Drive Platform Transfer Van Load Capacity: 1-300T
Table Size: Customized Height: Customized
Control Method: Remote Control/Pendant Certificates: CE/ISO/SGS
Application: Industrial Filed
High Light:

300t battery powered transfer cart

,

300t trackless transfer cart

,

odm battery powered transfer cart

High quality Warehouse station use Trackless Battery powered Transfer cart







Descraptions



The BWP battery drive platform transfer van cargo transfer carts run on factory floor is powered by battery, electric cable and generator. It can spin around 360 degrees. All the cars are equipped with warning alarm, safety inspection device and Dead-man control. It can also be equipped with automatic intelligent charger and PLC control system, so that it can realize full-automatic control.

The battery drive platform transfer van cargo transfer carts run on factory floor can be equipped as per your requirement.As per the transported cargoes,The V frame, U frame, rubber pad, wooden pad, weighing device...can be equipped.As per the working environment, the anti-high temperature, anti-explosion, anti-rust, anti-skid measure can be adopted properly.

Warehouse Station Use Trackless 300t Battery Powered Transfer Cart 0





Technical Parameters
Model BWP-5t BWP-20t BWP-30t BWP-40t BWP-50t
Rated Load(t) 5 20 30 40 50
Impacted rated load(t) 7.5 30 45 60 75
Structure of Frame Steel plates welded, beam
thickness of the steel plate 8 14 14 16 16
Cart weight(t) 4.3 7.9 8.8 10 10.5
Max. wheel load (t) 2.8 5.6 7.7 10 12
Ground requirement Cement floor or Steel plate ground
Ground Clearance(mm) 50 50 50 50 50
Table size (mm) 3000 X 2000 4500 X 2200 5000 X 2200 5500 X 2300 6000 X 2300
Height of the whole cart (mm) 450 600 650 700 700
Wheel base (mm) 1500 1700 1700 1800 1800
Axles distance (mm) 2500 3900 4300 4800 5200
Turning radius (mm) 2501 3901 4301 4801 5201
Turning type Turning while driving with no stop
Control method for turning Control button
Turning structure Mechanical
Motor power (KW) 3.5 7 10 12 15
Wheel diameter (mm) 300 (4) 400 (4) 400 (6) 500 (6) 500 (6)
Wheel material ZG55+hydropurture
Running speed (m/min) 0-15 0-12
Brake principle Electric magnetic brake
Ground balance Mechanical automatic adjustment
Operation method With wire or no wire
Battery model D-250 24pieces D-440 24pieces D-250 36pieces D-330 36pieces D-440 36pieces
Battery maintainance Free of maintainance
Charger's installation Installed on cart Split-type
Cart color Yellow and warning sign
Charger's function Automatic stop for obstacles
Radar control 3-0.3 m, Automatic stop for obstacles
Warning equipment Sound and light
Other functions Turning light, night light and power display





Why choose us



Henan Perfect Handling Equipment Co., Ltd is a professional & international manufacturing factory specialized in researching, developing, producing and selling material handling equipment.Based on modern plant and advanced production equipment, we can produce all kinds of handling equipment from 1-1300 tons, our main products including BDG conductor rail transfer cart, BJT cable drum transfer cart, BHX safety sliding line transfer cart, BXC battery type transfer cart, BTL towed cable type transfer cart, BP non-power type transfer cart, BQY train towed type transfer cart, BWP trackless type and special type transfer cart, such as turning, trackless,ladle, hydraulic lifting, ferry, painting room, blasting booth etc.

Warehouse Station Use Trackless 300t Battery Powered Transfer Cart 1



Functions & Advantages
  • Anti-explosion,Anti-high temperature;
  • Running on the concrete floor;
  • Powered by battery;
  • With lifting holes, convenient to shipment;
  • Unlimited running distance;
  • Safe and convenient operation ;
  • High using frequency ;
  • Automatic dead-man control;
  • Warehouse Station Use Trackless 300t Battery Powered Transfer Cart 2
