Product Details:
Payment & Shipping Terms:
|
| Product Name: | 30t Flat Bed Industry Material Handling Electric Trackless Transfer Car With Remote And Hand Wireless Control | Type: | Material Trackless Transfer Cart |
|---|---|---|---|
| Battery Capacity(Ah): | 180-600 | Ground Requirement: | Cement Floor |
| Ground Clearance(mm): | 50 | Wheels Base(mm): | 1500-1800 |
| Motor Power(Kw): | 3.5-15 | Running Speed(m/min): | 0-15 |
| High Light: | 30t Material Transfer Cart,Flatbed Material Transfer Cart,Flatbed Transfer Trolley |
||
Warehouse Use Trackless Flatbed Material With Remote Control Transfer cart
Descraptions
The series transfer cart usually,accumulator,mains powered and generator are choose as power source.The current is supplied and generator are choose as power source.The Cart is supplied to pulling motor through electric control system,which makes the transfer cart start,stop,move background,turn around and realize other functions.Also, we will provide intelligent automatic rapid charger with the car. Positioning fixture, lift platform and other assistive device are optional to meet different demands on various occasions.
Technical parameter table
| Rated Load(T) | 5 | 10 | 15 | 20 | 30 | 40 | 50 |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Wheel Base(mm) | 1500 | 1500 | 1500 | 1700 | 1700 | 1800 | 1800 |
| Turnning Radius(mm) | 2501 | 3101 | 3401 | 3901 | 4301 | 4801 | 5201 |
| Axles Distance(mm) | 2500 | 3100 | 3400 | 3900 | 4300 | 4800 | 5200 |
| Motor Power(Kw) | 3.5 | 5 | 6 | 7 | 10 | 12 | 15 |
| Running Speed(m/min) | 0-15 | 0-15 | 0-15 | 0-15 | 0-15 | 0-12 | 0-12 |
| Cart Weight(t) | 4.3 | 5.3 | 6.6 | 7.9 | 8.8 | 10 | 10.5 |
| Impacted Rated Load(t) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 |
| Battery Capacity(Ah) | 180 | 160 | 180 | 180 | 250 | 300 | 330 |
| Battery Voltage(v) | 36 | 48 | 48 | 48 | 48 | 48 | 48 |
| Wheel Quantity | 4 | 4 | 4 | 4 | 44 | 4 | 4 |
| Ground Requirement | Cement Floor | Cement Floor | Cement Floor | Cement Floor | Cement Floor | Cement Floor |
Cement Floor
|
Application
Stable and flexible during the turning in small space, we have optimized the steering mechanism, wheel press and frame rigidity to make it available for linkage of several trolleys. The Carts has been highly approved by our customers.
CNC Cutting and Preliminary Assembling
Paint finish and Debugging
Packaging & Shipping
The Heavy Load Industrial Handling body is packed with tarp, the cart wheel and parts will be packed with wooden case.
cart lenght is less than 5.9m, the width is less than 2.2m. Industrial Large Motorized Transport Carts will be transported by 20ft container. If the length is longer than 5.9m and less than 12m, it will be transported by 40ft container.If the quantity is 2 sets or 3 sets, they can be transported by full container. If the quantity is 1 set, it can be transported by LCL Container.If the length is less than 12m, the width is beyond 2.2m. It needs to be transported by FR container(20 or 40 ft). If the cart is beyond above dimension, It needs to be transported by BB container.Determine the size & material of the box according to the shape & number of products.
Price Term: EXW, FOB, CIF, C&F,DDU, DDP.
Certifications
Q & A
1.Q:What is the MOQ?
A: At present, our MOQ is 1 set.
2. Q: What is the size and load of this Trackless Transfer Car ?
A:The size and load of our this trackless transfer car is customized design according to your requirement.
3. Q:Can choose the power supply?
4. Q: What is the leading time, delivery term, and payment term ?
A: Usually our leading time is 45 days, for some special rail coil transfer car, such as rail coil transfer car, it maybe longer to 60 days. About the delivery term, we accept EXW, FOB, CIF, DDU. About the payment, we accept T/T or L/C.
