Trackless Battery Power Q235B Material Transfer Trolley For Paper Making

Trackless Battery Power Q235B Material Transfer Trolley For Paper Making
Trackless Battery Power Q235B Material Transfer Trolley For Paper Making
video play

Large Image :  Trackless Battery Power Q235B Material Transfer Trolley For Paper Making

Product Details:
Place of Origin: Xinxiang, China
Brand Name: PERFECT
Certification: CE, SGS, ISO
Model Number: BWP
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Packaging Details: The whole cart is package with tarp, and parts will be packed by wood case
Delivery Time: 45 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 75 Sets per month
Detailed Product Description
Running Ground: Cement Or Smooth Ground Operation Mode: Pandent And Remote Controller
Cart Frame: Q235B Rail Gauge: 1435mm (Customized)
Color: Yellow, Customized Working Time: 4-5 Hours
Wheel Type: Polyurethane Solid Wheels Safrty Device: Buffer, Alarm Light, Emergency Stop Buttons
Special Function: Anti-Explosion, Heat-Resistant, Lifting, Dumpling Dimension: Customized
High Light:

Q235B Material Transfer Trolley

,

Flatbed Material Transfer Trolley

,

Flatbed Electric Transfer Cart

Customization Color Trackless battery power transfer trolley For Paper Making



Why choose this serise Cart



Our BWP series pallet transport vehicle is powered by storaged power. The battery is fitted in the inner of the vehicle. It's elegant, reliable and high efficient. The wheel is made up of polyurethane solid wheels to make sure safe and quiet driving. You need to charge it for 8 hours and then keep it work for over 4 hours. It's a right transfer vehicle for you!

Trackless Battery Power Q235B Material Transfer Trolley For Paper Making 0



Advantages



Maybe you are interested in our products and want to buy trackless pallet transport vehicle, I think you can have a sincere consideration in our products.It's powered by electric devices, so when you are operating it, you can't feel much noise. It causes low noise level and give workers a good working environment.
We always try our best to make sure the safety of the operators and the material handled. We do care the safety of everyone involved in the job. Our vehicles are easy to drive, so as soon as you get it you will be able to use it to transport your loads. We will support you to make the best by using our products.



Parameters of Trackless Pallet Transport Vehicle



Model BWP-5t BWP-20t BWP-30t BWP-40t BWP-50t
Rated Load(t) 5 20 30 40 50
Impacted rated load(t) 5 20 30 40 50
Structure of Frame Steel plates welded, beam
thickness of the steel plate 8 14 14 16 16
Cart weight(t) 4.3 7.9 8.8 10 10.5
Max. wheel load (t) 2.8 5.6 7.7 10 12
Ground requirement Cement floor or Steel plate ground
Ground Clearance(mm) 50 50 50 50 50
Table size (mm) 3000*2000 4500*2200 5000*2200 5500*2300 6000*2300
Height of the whole cart (mm) 450 600 650 700 700
Wheel base (mm) 1500 1700 1700 1800 1800
Axles distance (mm) 2500 3900 4300 4800 5200
Turning radius (mm) 2501 3901 4301 4801 5201
Turning type Turning while driving with no stop
Control method for turning Control button
Turning structure Mechanical
Motor power (KW) 3.5 7 10 12 15
Wheel diameter (mm) 300 (4) 400 (4) 400 (6) 500 (6) 500 (6)
Wheel material ZG55+hydropurture
Running speed (m/min) 0-15 0-12
Brake principle Electric magnetic brake
Ground balance mechanical automatic adjustment
Operation method With wire or no wire
Battery model D-250 24pieces D-440 24pieces D-250 36pieces D-330 36pieces D-440 36pieces
Charger's installation Installed on cart Split-type
Cart color Yellow and warning sign
Radar control 3-0.3 m, Automatic stop for obstacles
Other functions Turning light, night light and power display



our certificate



Trackless Battery Power Q235B Material Transfer Trolley For Paper Making 1







Help you to choose the most suitable cart

Thank you very much for looking through the information above. If you are interested in our products, please send us an E-mail and tell us the following information. Thank you!

  • 1.What material/cargo are you going to transfer?
  • 2.What load capacity do you want?
  • 3.What kind of ground does the transfer cart operate on? (rails or cement floor)
  • 4.What’s the specification table size ? (length,width and height)
  • 5.How long is the running distance?
  • 6.How many working hours do you have everyday?
