Pallet Electric Bogie 360 Degree Material Handling Turntable Running On Rail

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Pallet Electric Bogie 360 Degree Material Handling Turntable Running On Rail

Product Details:
Place of Origin: China(mainland)
Brand Name: transfer cart with turnplate on rail
Certification: CE ISO SGS
Model Number: transfer cart with turnplate on rail
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 2000~8000 month
Packaging Details: trap and wooden case
Delivery Time: 20 work days after received balance payment
Supply Ability: 100 sets month
Detailed Product Description
Product Name: Transfer Cart With Turnplate On Rail Capacity: 1-300 Ton
Running Speed: 0-20m/min Color: Customized
Material: Q235 After-sales Service Provided: Engineers Available To Service Machinery
High Light:

pallet material handling turntable

,

q235 material handling turntable

,

rail material handling turntable



Pallet Electric Handling Bogie 360 degree Turntable Running on Rail





Product Description



Henan Perfect Handling Equipment Co., Ltd. is specializing in the design and manufacture of heavy material transport system to solve every material handling requirement. Our product includes Industrial Trailers, Transfer Cars, Electric Railway Transfer Trolley, Battery Operated Transport Trolley, Coil and pipes Carrier Equipment, Ladle Handling Equipment, Hydraulic Lift Table, Turntables and many other specialty items.Our line of Industrial Transfer Carts are designed and manufactured to accommodate the needs of a wide range of industries including Steel, Aluminum, Automotive, Heavy Manufacturing and others. These material handling equipment are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

Pallet Electric Bogie 360 Degree Material Handling Turntable Running On Rail 0



Product Details

DC drive, no cable, low frequency, unrestricted transportation distance. Use time is not more than 8 hours a day, transport distance is relatively long, equipped with ordinary rail working occasions. Battery track flat car is known for its simple operation, easy use, no distance restriction, no weather impact, and its load tonnage can also reach more than 300 tons. It is a popular type of car for workshop transshipment and warehouse logistics.

 transfer cart with turnplate on rail



Application Scene

Another English name is turntable. In fact, the two English names mean the display cabinet turntable, the latter refers to the table turntable. Now the use of turntable is very wide. There is also a TV turntable, a very market-oriented product, and model turntable. The turntable in the mechanical die, the turntable for photographic equipment and the model turntable. The largest automobile display turntable is made of aluminum alloy, stainless steel and wood.

 transfer cart with turnplate on rail









4. Parameter of Electric Handling Bogie

Model BDG-2t BDG-16t BDG-30t BDG-50t BDG-100t BDG-150
Rated Load(t) 2 16 30 50 100 150
Table Size (mm) Length(L) 2000 4000 4500 5500 6500 10000
Width(W) 1500 2000 2200 2500 2800 3000
Height(H) 450 500 600 650 850 1200
Wheel Base(mm) 1200 2800 3200 4200 4900 7000
Rail Inner Gauge (mm) 1200 1435 1435 1435 2000 2000
Wheel Diameter (mm) 270 350 400 500 600 600
Running Speed (m/min) 0-25 0-20 0-20 0-20 0-20 0-18
Running Distance (m) 70 70 70 50 50 50
Motor Power(kw) 1 2 3.5 5.5 11 15
Transformer Power (KVA) 3 6.8 10 10 30 30
Transformer Quantity 1 1 1 1 1 1
Running Distance (m) 70 70 70 50 50 50
Recommended Rail Model P15 P24 P43 P43 QU100 QU100



Pallet Electric Bogie 360 Degree Material Handling Turntable Running On Rail 3
