50t Heavy Duty Transfer Cart Transport Material Running Trackless

50t Heavy Duty Transfer Cart Transport Material Running Trackless
50t Heavy Duty Transfer Cart Transport Material Running Trackless 50t Heavy Duty Transfer Cart Transport Material Running Trackless 50t Heavy Duty Transfer Cart Transport Material Running Trackless 50t Heavy Duty Transfer Cart Transport Material Running Trackless

Large Image :  50t Heavy Duty Transfer Cart Transport Material Running Trackless

Product Details:
Place of Origin: China(Mainland)
Brand Name: transfer cart transport material
Certification: CE ISO SGS
Model Number: transfer cart transport material
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: usd 3000~7900set
Packaging Details: trap and wooden case
Delivery Time: 20 work days after received balance payment
Supply Ability: 100sets month
Detailed Product Description
Product Name: Transfer Cart Transport Material Capacity: Customized
Color: Customized Running Speed: 0-20m/min
After-sales Service Provided: Engineers Available To Service Machinery
High Light:

50t heavy duty transfer cart

,

customization heavy duty transfer cart

,

customization trackless transfer trolley

50T Heavy duty Transport Material Battery Transfer Cart Running Trackless



Introductions

Battery Transfer Car is powered by storage battery, It is a kind of transport vehicles indoor and outdoor, is suitable to be used in the long running distance transportation and low using frequency without extra power supply. The batteries supply electricity to the DC motor through the electrical control system. Then the reducer drives the wheels of the cart start, stop, go forward and backward, turn left, right and around in 360°, the speed also can be adjusted.
Battery is easy to replace within 5min , full load continuous running 6 hours , the Intelligent charging device can charge the battery full within 8 hours. so It was widely used in machinery factories, warehouses and metallurgical plants as a workshop transport or with the crane transport heavy loads over cross.



50t Heavy Duty Transfer Cart Transport Material Running Trackless 0


Technical Parameter of transfer cart for workshop transportation

Model BWP-5t BWP-20t BWP-30t BWP-40t BWP-50t
Rated Load(t) 5 20 30 40 50
Max. Wheel Load (t) 2.8 5.6 7.7 10 12
Ground Requirement Cement floor or Steel plate ground
Ground Clearance(mm) 50 50 50 50 50
Table Size (mm) 3000 X 2000 4500 X 2200 5000 X 2200 5500 X 2300 6000 X 2300
Height (mm) 450 600 650 700 700
Wheel Base (mm) 1500 1700 1700 1800 1800
Axles Distance (mm) 2500 3900 4300 4800 5200
Turning Radius (mm) 2501 3901 4301 4801 5201
Turning Structure Mechanical
Motor Power (KW) 3.5 7 10 12 15
Wheel Diameter (mm) 300 (4) 400 (4) 400 (6) 500 (6) 500 (6)
Wheel Material ZG55+hydropurture
Running Speed (m/min) 0-15 0-12
Brake Principle Electric magnetic brake
Operation Method Raido Remote Control
Battery Maintainance Free of maintainance
Charger's Installation Installed on cart Split-type
Cart Color Customized
Charger's Function Automatically cut off the power when the battery is fully charged
Radar Control 3-0.3 m, Automatic stop for obstacles
Warning Equipment Horn and Flash Light
Other Functions Turning light, night light and power display



Q&A

1.What Product Handling Applications Use Transfer Carts?
1. Coils (V-Groove deck)
2. Tanks (size/stability for uniformly distributed loads)
3. Assemblies (fixture cradle) for a complete build or to send a partially completed product to the next station (tractors, heavy equipment machinery)
4. Sub-Assembly shuttle from one line to another line
5. Maintenance cart for motors and pumps
6. Equipment support (stand-off deck) for navigating loads to locations with a plant facility
7. Material shuttle for steel tubing (flat decking with guard rails)
8. Elevating platform for assembly process (integrated screw-jack table)
9. Sand casting (flat decking)
2. What Are The Advantages of Using a Transfer Cart?
For smaller loads, manual carts can be dedicated to specific work place activities such as shuttling materials. This often makes the carts more available for use. Transfer carts are more accommodating for moving long loads through restrictive passage ways or doorways. For heavier loads transfer carts are an excellent affordable choice for their ability to handle heavy loads. Transfer carts are compact in design and work well in areas with limited floor area. Another advantage over lift trucks is how the cart deck can be customized to suit specific loads.
3. How can Transfer Carts be customized?
Please tell us:
What load or product will be transferred onto the cart?
What is the weight of the heaviest lift or load?
What are the dimensions? (Length; Width ; Height)
What is the trip time and frequency? (# of Trips per , Shifts per day:)
What is the travel area you need to cover? (Rail/cement floor, Indoor/Outdoor, straight line travel, etc)
What is the distance to travel?
Other relevant information or using condition.

50t Heavy Duty Transfer Cart Transport Material Running Trackless 1
