PLC 1-50t Coil Transfer Trolley Railway Transport

PLC 1-50t Coil Transfer Trolley Railway Transport
PLC 1-50t Coil Transfer Trolley Railway Transport PLC 1-50t Coil Transfer Trolley Railway Transport PLC 1-50t Coil Transfer Trolley Railway Transport PLC 1-50t Coil Transfer Trolley Railway Transport

Large Image :  PLC 1-50t Coil Transfer Trolley Railway Transport

Product Details:
Place of Origin: Xinxiang, China
Brand Name: PERFECT
Certification: CE, SGS, ISO
Model Number: BTL
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Packaging Details: The whole cart is package with tarp, and parts will be packed by wood case
Delivery Time: 45 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 75 Sets per month
Detailed Product Description
Load Capacity: Customized/1-300 Tons Operation Mode: Pandent And Remote Controller Or PLC
Application: Factory, Warehouse, Port, Construction, Steel Structure Rail Gauge: 1435mm (Customized)
Color: Yellow/Customized Working Time: No Limited
Wheel Type: Cast Steel Wheel Safrty Device: Buffer, Alarm Light, Emergency Stop Buttons
Special Function: Anti-Explosion, Heat-Resistant, Lifting, Dumpling Additional Unit: Optional (Hydraulic Lifting Table/ Roller Guard Bar)
High Light:

1t coil transfer trolley

,

customization coil transfer trolley

,

customization coil transfer cart

1-50T High Quality Factory use Coils Railway Transport Cart Oversea service



Introduction



Our coil transfer cart are used to transport steel coils and pipes for metal industry. This coil transfer Cars are designed to be an extremely cost effective, safe and flexible load moving alternative.
The steel coil rail car is also called a heavy transporter, headless transporter or self-propelled modular transporter. Our coil transfer carts are specially designed for coil, pipe and other round material transportation. When the goods are loaded, we can make sure the car moves safely and the goods are in a very safe condition.



PLC 1-50t Coil Transfer Trolley Railway Transport 0

Advantages of High Frequency Use Timber Mill Electric Carriage​



Low noise
It's powered by electric devices, so when you are operating it, you can't feel much noise. It causes low noise level and give workers a good working environment.
Maximum safety
We always try our best to make sure the safety of the operators and the material handled. We do care the safety of everyone involved in the job.
Easy for operation
Our vehicles are easy to drive, so as soon as you get it you will be able to use it to transport your loads. We will support you to make the best by using our products.
Easy to implement into manufacturing process
Operates on standard floors; Do not require complex or permanent installation
Suitable for All Kinds of Weight
The steering battery powered trolley is superb for handling both small and extremely huge loads for its modular fabrication and its high payloads: up to 300 ton for each trolley.

PLC 1-50t Coil Transfer Trolley Railway Transport 1



Parameter

Model BJT-2t BJT-20t BJT-50t BJT-100t BJT-150t
Rated Load(t) 2 20 50 100 150
Table Size (mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Height(H) 500 600 700 1000 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 200 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 0.8 2.5 5.5 11 15
Running Distance(m) 25 30 50 50 50
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Reference Weight(t) 2.5 5.6 7.8 14.1 26.2
Recommended Rail Model P15 P24 P43 QU100 QU100



Company Strength

Henan Perfect Handling Equipment Co., Ltd is a steel high frequency use timber mill electric carriage​ manufacturing enterprise integrated in scientific research, production and marketing. There are more than 100 workers including 3 senior engineers and 7 engineers and 10 technicians. The scientific management, advanced processing technology and innovative manufacturing theory make the company become the material handling manufacturing and exporting base in China.

PLC 1-50t Coil Transfer Trolley Railway Transport 2
