Product Details:
Payment & Shipping Terms:
|
| Powered Source: | Conductor Rails / Storage Battery / Lead-acid Battery | Operation Mode: | Pandent And Remote Controller And PLC |
|---|---|---|---|
| Cart Frame: | Q235B | Rail Gauge: | 1435mm (Customized) |
| Color: | Yellow/Customized | Working Hours: | No Limited |
| Wheel Type: | Cast Steel Wheel | Safrty Device: | Buffer, Alarm Light, Emergency Stop Buttons |
| Special Function: | Anti-Explosion, Heat-Resistant, Lifting, Dumpling | Dimension: | Customized |
| High Light: | angle box wheel rail transfer cart,railway transportation rail transfer cart,flatbed material handling rail transfer cart |
||
|
Model |
BDG-2t |
BDG-16t |
BDG-30t |
BDG-50t |
BDG-100t |
BDG-150 |
|
|
Rated Load(t) |
2 |
16 |
30 |
50 |
100 |
150 |
|
|
Table Size (mm) |
Length(L) |
2000 |
4000 |
4500 |
5500 |
6500 |
10000 |
|
Width(W) |
1500 |
2000 |
2200 |
2500 |
2800 |
3000 |
|
|
Height(H) |
450 |
500 |
600 |
650 |
850 |
1200 |
|
|
Wheel Base(mm) |
1200 |
2800 |
3200 |
4200 |
4900 |
7000 |
|
|
Rail Inner Gauge (mm) |
1200 |
1435 |
1435 |
1435 |
2000 |
2000 |
|
|
Wheel Diameter (mm) |
270 |
350 |
400 |
500 |
600 |
600 |
|
|
Running Speed (m/min) |
0-25 |
0-20 |
0-20 |
0-20 |
0-20 |
0-18 |
|
|
Running Distance (m) |
70 |
70 |
70 |
50 |
50 |
50 |
|
|
Motor Power(kw) |
1 |
2 |
3.5 |
5.5 |
11 |
15 |
|
|
Transformer Power (KVA) |
3 |
6.8 |
10 |
10 |
30 |
30 |
|
|
Transformer Quantity |
1 |
1 |
1 |
1 |
1 |
1 |
|
|
Running Distance (m) |
70 |
70 |
70 |
50 |
50 |
50 |
|
|
Recommended Rail Model |
P15 |
P24 |
P43 |
P43 |
QU100 |
QU100 |
|
Large Capacity Transfer Cart Transportation: With large capacity and dimension, the transfer cart is delivery through flat rack.
Large Duty transfer car Transportation: With small table size, the transfer car can be delivery into 20’ container.
Small Dimension Rail Cart: With small dimension, the two or more rail carts can be put into a container.
Long Flat Bed Transfer Trolley Transportation: With long flatbed and small width, the transfer trolley can be delivered through a 40’ container.
