Electric Handling 30 Ton Material Transfer Cart Diesel Engine Powered

Electric Handling 30 Ton Material Transfer Cart Diesel Engine Powered
Electric Handling 30 Ton Material Transfer Cart Diesel Engine Powered Electric Handling 30 Ton Material Transfer Cart Diesel Engine Powered Electric Handling 30 Ton Material Transfer Cart Diesel Engine Powered Electric Handling 30 Ton Material Transfer Cart Diesel Engine Powered

Large Image :  Electric Handling 30 Ton Material Transfer Cart Diesel Engine Powered

Product Details:
Place of Origin: China(mainland)
Brand Name: 20 ton diesel engine powered transfer cart
Certification: CE ISO SGS
Model Number: 20 ton diesel engine powered transfer cart
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 3000~7500 set
Packaging Details: trap and wooden case
Delivery Time: 20 work days after received balance payment
Supply Ability: 100 sets month
Detailed Product Description
Product Name: 20 Ton Diesel Engine Powered Transfer Cart Warranty: 12 Months
Capacity: 1-300ton Running Speed: 0-20m/min
After-sales Service Provided: Engineers Available To Service Machinery Feature: Easy Operation
High Light:

handling 30 ton material transfer cart

,

diesel engine powered material transfer cart

,

diesel engine powered electric transfer cart

Top Quality Factory Electric Material Handling limit 30 ton diesel engine powered cart







Introduction of Electric Vehicle

PERFECT Electric Transportation Trolley are used to transport steel coils and pipes for metal industry. This Electric Railroad Vehicle are designed to be an extremely cost effective, safe and flexible load moving alternative.
The Transfer Carts are manual guide vehicles equipped with specialized drive systems which make it possible to easily, precisely and safely move up to 200 tons. The Electric Railroad Vehicle is sometimes called a heavy transporter, headless transporter or self-propelled modular transporter.



Electric Handling 30 Ton Material Transfer Cart Diesel Engine Powered 0





Technical Parameter

Model BDGS-2t BDGS-20t BDGS-50t BDGS-100t BDGS-150t
Rated Load(t) 2 20 50 100 150
Table Size(mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Heigth(H) 450 550 650 850 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 2000 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 0.8 2.5 5.5 11 15
Transformer Power(KVA) 3 6.8 10 30 30
Transformer Quanity 1 1 1 1 1
Running Distance(m) 70 70 50 50 50
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Reference Weight(t) 2.8 5.9 8 14.6 26.8
Recommended Rail Model P15 P24 P43 QU100 QU100



Application of Rail Electric cart


PERFECT Electric Railroad Vehicle are operating in many shipping lines, stevedores, concrete manufacturers, foundries, steel mills, etc. We have supplied Hybrid Transfer Cart in the world for moving heavy duty materials and equipments inside and outside the plant by electric traction and driving long distances. And also Electric Railroad Vehicle are mainly used to solve manoeuvrability problems in tight spaces.



Electric Handling 30 Ton Material Transfer Cart Diesel Engine Powered 1

Our Factory


We are a collection of research and development, design, manufacturing as one of professional international company of handling equipment.

Our company specialized 16 years, getting 8 national patents, so we have the best quality and the lower price.
