30t Heavy Load Transfer Cart Customization Color Bogie Rail Material Handling Equipment

30t Heavy Load Transfer Cart Customization Color Bogie Rail Material Handling Equipment
30t Heavy Load Transfer Cart Customization Color Bogie Rail Material Handling Equipment 30t Heavy Load Transfer Cart Customization Color Bogie Rail Material Handling Equipment 30t Heavy Load Transfer Cart Customization Color Bogie Rail Material Handling Equipment 30t Heavy Load Transfer Cart Customization Color Bogie Rail Material Handling Equipment

Large Image :  30t Heavy Load Transfer Cart Customization Color Bogie Rail Material Handling Equipment

Product Details:
Place of Origin: China(mainland)
Brand Name: 20t electric transfer trolley
Certification: CE ISO SGS
Model Number: 20t electric transfer trolley
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 2000~7500 set
Packaging Details: trap and wooden case
Delivery Time: 20 work days after received balance payment
Supply Ability: 100 sets month
Detailed Product Description
Product Name: 20t Electric Transfer Trolley Capacity: 1-300T
Dimension: Customized As Practical Needs Color: Customized
Application: Industrial Filed Feature: Easy Operation
Certificates: CE ISO SGS
High Light:

30t heavy load transfer cart

,

customization color heavy load transfer cart

,

bogie rail heavy duty transfer cart

30t Heavy load Customization color Bogie Rail For Material handling Equipment supplier


Product from us

Solid design, thickened of welded steel plate, and anti shape-shifting bearings installed in plant for carrying aluminum coils and steel pipes, one place to another place, with our rich industrial experience; We have been able to catch up with a wide range of coil transfer truck. They occupy sufficient ground clearance. Customizable features like rotating light, table size, warning alarm, storage battery, low voltage rail, cable reliving drum (Spring Drum/Magnetic Coupling Drum) can be supplied as per the customer's needs and applications.


30t Heavy Load Transfer Cart Customization Color Bogie Rail Material Handling Equipment 0



Detailed Image


20t electric transfer trolley

Technical Parameters

Model 2t 20t 50t 100t 150t
Rated Load(t) 2 20 50 100 150
Table Size(mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Heigth(H) 450 550 650 850 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 2000 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 25 20 20 20 18
Motor Power(kw) 0.8 2.5 5.5 11 15
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Reference Weight(t) 2.3 5.5 7.6 13.9 26
Recommended Rail Model P15 P24 P43 QU100 QU100



Advantages



---- Low noise It causes low noise level.
---- Maximum safety Offers guarantee of maximum safety for operators and for the material handled. We really care about the safety of everyone involved in the job.
---- Easy for operation These vehicles are easy to drive, so as soon as you get it you will be able to use it to transport your loads. We will support you to make the best out of your heavy load transporter.
---- Easy to implement into manufacturing process Operates on standard floors; Do not require complex or permanent installation
---- Suitable for All Kinds of Weight The steering battery powered trolley is superb for handling both small and extremely huge loads for its modular fabrication and its high payloads: up to 300 ton for each trolley.

30t Heavy Load Transfer Cart Customization Color Bogie Rail Material Handling Equipment 2



Q/A

Will A Transfer Cart Be A Good Solution?
A good question to ask since there are many material handling solutions on the market! Which one is the right choice? For starters, transfer carts are moveable platforms used for the horizontal movement of materials, assemblies, and other items. Consideration must be given to the weight of the load and the travel requirements for the application.
What Are The Advantages of Using a Transfer Cart?
For smaller loads, manual carts can be dedicated to specific work place activities such as shuttling materials. This often makes the carts more available for use. Transfer carts are more accommodating for moving long loads through restrictive passage ways or doorways. For heavier loads transfer carts are an excellent affordable choice for their ability to handle heavy loads. Transfer carts are compact in design and work well in areas with limited floor area. Another advantage over lift trucks is how the cart deck can be customized to suit specific loads.
What Product Handling Applications Use Transfer Carts?
1. Coils (V-Groove deck)
2. Tanks (size/stability for uniformly distributed loads)
3. Assemblies (fixture cradle) for a complete build or to send a partially completed product to the next station (tractors, heavy equipment machinery)
4. Sub-Assembly shuttle from one line to another line
5. Maintenance cart for motors and pumps
6. Equipment support (stand-off deck) for navigating loads to locations with a plant facility
7. Material shuttle for steel tubing (flat decking with guard rails)
8. Elevating platform for assembly process (integrated screw-jack table)
9. Sand casting (flat decking)
