Stogage Battery Transfer Cart 1-300T Capacity For Material Transportation

Stogage Battery Transfer Cart 1-300T Capacity For Material Transportation
Stogage Battery Transfer Cart 1-300T Capacity For Material Transportation Stogage Battery Transfer Cart 1-300T Capacity For Material Transportation Stogage Battery Transfer Cart 1-300T Capacity For Material Transportation Stogage Battery Transfer Cart 1-300T Capacity For Material Transportation

Large Image :  Stogage Battery Transfer Cart 1-300T Capacity For Material Transportation

Product Details:
Place of Origin: China(mainland)
Brand Name: stogage battery powered transfer cart on rail
Certification: CE ISO SGS
Model Number: stogage battery powered transfer cart on rail
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 2000~7500 set
Packaging Details: trap and wooden case
Delivery Time: 20 work days after received balance payment
Supply Ability: 100 sets month
Detailed Product Description
Product Name: Stogage Battery Powered Transfer Cart On Rail Material: Q235
Powered Source: Battery Capacity: 1-300T
Warranty: 12 Months Feature: Easy Operation
High Light:

battery transfer carriage

,

battery operated cart



stogage battery powered transfer cart on rail for material transportation




This stogage battery powered transfer cart on rail for material transportation is usually used at ship yard, plant and factory, certain production line. The stogage battery powered transfer cart on rail for material transportation could get power from the battery. The stogage battery powered transfer cart on rail for material transportation was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and/or products through manufacturing facilities. stogage battery powered transfer cart on rail for material transportation construction is based on our world renowned rail flat electric transfer cart and provides controlled movement of heavy and oversized loads such as dies, coils and work in progress. Our rail flat electric transfer cart is available in a number of configurations specifically designed to suit the needs of our customers.

rail flat electric transfer cart


Technical Parameter of stogage battery powered transfer cart on rail
Model 2t 20t 50t 100t 150t
Rated Load(t) 2 20 50 100 150
Table Size(mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Heigth(H) 450 550 650 900 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 2000 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 1 2.2 5 10 15
Running time When Full Load 4.32 4 3.3 3.2 2.9
Running Distance for Once Charge(KM) 6.5 4.8 4 3.8 3.2
Reference Weight(t) 2.8 5.9 8 14.6 26.8
Recommended Rail Model P15 P24 P43 QU100 QU100

Process Line



Motorised steel tube transfer carriage for alloy factory transport


 battery power rail flat electric transfer cart


 battery power rail flat electric transfer cart


Application Sites

The Electric trailer dolly is mainly applied in assembly line(ring production line,loop production line),metallurgy industry(steel lade),warehouse transport,ship industry(maintenance, assemcle,container transport),work piece transport in workshop,lathe transport,steel factory(steel billet,steel plate,steel coil,steel pipe,section steel structure),construction(bridge,simple building,concrete column,)petroleum industry(oil pump,sucker rod and parts),energy(polycrystalline silicon,generator,windmill),chemical industry(electrolytic cell,retort etc),railway(rail maintenance,rail welding,train tractor).
