Product Details:
Payment & Shipping Terms:
|
| Application: | Material Or Heavy Machine Parts Handling / Transfer | Load Capacity: | Customized |
|---|---|---|---|
| Power Mode: | Storage Battery | Control Mode: | Pendant/Remote/PLC Control |
| Material: | Q235 | Dimension: | Customized As Required |
| Runing Speed: | 0-30m/min | Special Function: | Anti-Explosion, Heat-Resistant, Lifting, Dumpling |
| Turning Structure: | Mechanical | Battery Type: | Free Of Maintenance |
| High Light: | trackless battery powered transfer cart,battery powered transfer cart 30m/min,trackless electric battery powered transfer cart |
||
The series transfer car is accumulator , mains powered and generator are chosen as power source .The current is supplied to pulling motor through electric control system, which makes the car start , stop, move forward , move backward ,turn around ,and realize other functions.
It is free maintenance battery with good quality Lifetime can upto 3-5 years.
This intelligent charge can protect battery when short circuit, overheating, delay start; When fully charged, the charger can automatically power off and shut down; It is portable, with advantage of small size and light weight.
BWP SERIES INDUSTRIAL TROLLEYS TECHNICAL PARAMETERS |
|||||
|
Model |
BWP-5t |
BWP-20t |
BWP-30t |
BWP-40t |
BWP-50t |
|
Rated Load(t) |
5 |
20 |
30 |
40 |
50 |
|
Impacted rated load(t) |
7.5 |
30 |
45 |
60 |
75 |
|
Structure of Frame |
Steel plates welded, beam |
||||
|
thickness of the steel plate |
8 |
14 |
14 |
16 |
16 |
|
Cart weight(t) |
4.3 |
7.9 |
8.8 |
10 |
10.5 |
|
Max. wheel load (t) |
2.8 |
5.6 |
7.7 |
10 |
12 |
|
Ground requirement |
Cement floor or Steel plate ground |
||||
|
Ground Clearance(mm) |
50 |
50 |
50 |
50 |
50 |
|
Table size (mm) |
3000*2000 |
4500*2200 |
5000*2200 |
5500*2300 |
6000*2300 |
|
Height of the whole cart (mm) |
450 |
600 |
650 |
700 |
700 |
|
Wheel base (mm) |
1500 |
1700 |
1700 |
1800 |
1800 |
|
Axles distance (mm) |
2500 |
3900 |
4300 |
4800 |
5200 |
|
Turning radius (mm) |
2501 |
3901 |
4301 |
4801 |
5201 |
|
Turning type |
Turning while driving with no stop |
||||
|
Control method for turning |
Control button |
||||
|
Turning structure |
Mechanical |
||||
|
Motor power (KW) |
3.5 |
7 |
10 |
12 |
15 |
|
Wheel diameter (mm) |
300 (4) |
400 (4) |
400 (6) |
500 (6) |
500 (6) |
|
Wheel material |
ZG55+hydropurture |
||||
|
Running speed (m/min) |
0-15 |
0-12 |
|||
|
Brake principle |
Electric magnetic brake |
||||
|
Ground balance |
mechanical automatic adjustment |
||||
|
Operation method |
With wire or no wire |
||||
|
Battery model |
D-250 24pieces |
D-440 24pieces |
D-250 36pieces |
D-330 36pieces |
D-440 36pieces |
|
Battery maintenance |
Free of maintenance |
||||
|
Charger's installation |
Installed on cart |
Split-type |
|||
|
Cart color |
Yellow and warning sign |
||||
|
Charger's function |
Automatic stop for obstacles |
||||
|
Radar control |
3-0.3 m, Automatic stop for obstacles |
||||
|
Warning equipment |
Sound and light |
||||
|
Other functions |
Turning light, night light and power display |
||||
Functional Customization
2.Explosion-proof occation
3.Lifting function
4.Rollover Function
5.Fixed-point stop
6.Positioning accuracy
7.Mesa precision
8.Scanning radar
9.Load-bearing function
Henan Perfect Handling Equipment Co., Ltd is devoted to manufacture and sell a wide range of handling equipment. We can provide and design solution to meet workshop transportation, material grading and transferring need. Our products have a wide application field including metallurgy industry, machinery manufacturing industry, mine industry, power industry, automobile assembly industry, food, pharmacy,shipyard, pigment, ceramics, chemical etc;
Our company located in Guandi Pioneer Park, and covered an area of 30,000 square meters. Rich design experience engineers and professional manufacturing personnel take you high quality product and service. Our products have been exported to Countries, such as USA, Germany, Netherlands, Thailand, Saudi Arabia, South Africa etc.
1.V frame
2.Roller support
3.Roller
4.Rubber plate
5.Aluminum pattern plate
6.Railing
7.Refractories
8.Damped buffer
9.Operating table
10.Wodden table
