Product Details:
Payment & Shipping Terms:
|
Powered Source: | Conductor Rail | Operation Mode: | Pandent And Remote Controller |
---|---|---|---|
Cart Frame: | Q235B | Rail Gauge: | 1435mm (Customized) |
Color: | Yellow And Blue/Customized | Working Time: | Whole Day |
Wheel Type: | Cast Steel Wheel | Safrty Device: | Buffer, Alarm Light, Emergency Stop Buttons |
Special Function: | Anti-Explosion, Heat-Resistant, Lifting, Dumpling | Dimension: | Customized |
High Light: | Material Handling Rail Flat Cart,1435mm Rail Material Handling Cart,Conductor Rail Material Handling Cart |
Product Introduction
PERFECT is specialized in designing and manufacturing of heavy duty material transport equipment. Our main products include material transfer carts, coils and pipes transport trolleys, industrial trailers, factory transport solution, electric warehouse carriages, ladle carts, motorized battery operated transfer vehicle and so on. The coil transfer carts are used to transport steel coils and pipes, die, machine parts, paper products for manufacturing industry; The factory transport solution is mainly to offer heavy duty horizontal transportation for manufacturing;while the motorized battery operated transport vehicle specially apply to transport heavy loads from one warehouse to another. With the steel box girder structure and safety devices make the electric transfer vehicle with easily, precisely and safely move up to 200 tons.
Application Sites
Uses of heavy duty industrial rail flat cart:
For horizontal load transfers of a wide range of material, we have the heavy duty, high quality transfer cart solutions you need. Transfer carts are used: to carry loads along assembly lines; transfer material from one work station to the next; store and transport an entire shift worth of production. They can even be used as a stable yet moveable machine base. With four different styles and standard capacities up to 60 tons, we have the solution you need and each style can be designed for your specific application.
Advantage
---- Low noise It causes low noise level.
---- Maximum safety Offers guarantee of maximum safety for operators and for the material handled. We really care about the safety of everyone involved in the job.
---- Easy for operation These vehicles are easy to drive, so as soon as you get it you will be able to use it to transport your loads. We will support you to make the best out of your heavy load transporter.
---- Easy to implement into manufacturing process Operates on standard floors; Do not require complex or permanent installation
---- Suitable for All Kinds of Weight The steering battery powered trolley is superb for handling both small and extremely huge loads for its modular fabrication and its high payloads: up to 300 ton for each trolley.
Technical Parameters---Rail Push Transfer Car
BDGZ SERIES TRANSFER CART TECHNIAL PARAMETER TABLE | |||||
Model | BDGZ-2t | BDGZ-16t | BDGZ-30t | BDGZ-50t | |
Rated Load(t) | 2 | 16 | 30 | 50 | |
Table Size (mm) | Length(L) | 2000 | 4000 | 4500 | 5500 |
Width(W) | 1500 | 2000 | 2200 | 2500 | |
Height(H) | 450 | 500 | 600 | 650 | |
Wheel Base(mm) | 1200 | 2800 | 3200 | 4200 | |
Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 1435 | |
Wheel Diameter(mm) | 270 | 350 | 400 | 500 | |
Wheel Quantity | 4 | 4 | 4 | 4 | |
Ground Clearance(mm) | 50 | 50 | 50 | 50 | |
Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | |
Motor Power(kw) | 1 | 2 | 3.5 | 5 | |
Transformer Power(KVA) | 3 | 6.8 | 10 | 20 | |
Transformer Quantity | 1 | 1 | 1 | 1 | |
Running Distance(m) | 70 | 70 | 70 | 50 | |
Max Wheel Load(KN) | 14.4 | 64.5 | 174 | 343.8 | |
Reference Weight(t) | 2.8 | 5.5 | 8 | 14.6 | |
Recommended Rail Model | P15 | P24 | P43 | QU100 |
