| Product Name: | Steel Trackless Die Transfer Cart | Powered Source: | Storaged Battery |
|---|---|---|---|
| Rail Gauge: | 1435mm, Customized | Cart Frame: | Q235B |
| Load Capacity: | 1-200T (Customized) | Color: | Yellow/Customized |
| Working Time: | 6~7 Hours | Wheel Type: | Polyurethane Coated Wheel |
| Safrty Device: | Buffer, Alarm Light, Emergency Stop Buttons | Special Function: | Anti-Explosion, Heat-Resistant, Lifting, Dumpling |
| High Light: | Steel Trackless Automated Workshop Bogie,Steel Beam Automated Workshop Bogie,1435mm Rail Gauge Die Transfer Cart |
||
Introduction of Steel Trackless Die Transfer Cart
Henan Perfect Handling Equipment Co., Ltd offers a wide range of automated workshop bogie specifically designed for the unique needs of stamping, molding, heavy die, bulk cargos, foundry and many other heavy duty things transporting or mold from die storage to the press line.
The body of the automated workshop bogie is made of thick steel plate and with super anti-distortion performance. All the bogies are equipped with warning alarm and security detection devices, and the alarm would ring and the car would stop immediately once there was any obstacle or pedestrian in the running path of the automated workshop bogie.
Application of Automated Workshop Bogie
PERFECTautomated workshop bogies are operating in many shipping lines, stevedores, concrete manufacturers, foundries, steel mills, etc. We have supplied hybrid automated workshop bogies in the world for moving molds inside and outside the plant by electric traction and driving long distances.And also automated workshop bogies are mainly used to solve manoeuvrability problems in tight spaces. Due to all possible steering programs, on either one or different axles, you can achieve tight turning radious. The propulsion can be either electric for in-plant load carts or batteries for long distances.
Parameters of Steel Trackless Die Transfer Cart
| Model | BWP-5t | BWP-20t | BWP-30t | BWP-40t | BWP-50t |
| Rated Load(t) | 5 | 20 | 30 | 40 | 50 |
| Impacted rated load(t) | 5 | 20 | 30 | 40 | 50 |
| Structure of Frame | Steel plates welded, beam | ||||
| thickness of the steel plate | 8 | 14 | 14 | 16 | 16 |
| Cart weight(t) | 4.3 | 7.9 | 8.8 | 10 | 10.5 |
| Max. wheel load (t) | 2.8 | 5.6 | 7.7 | 10 | 12 |
| Ground requirement | Cement floor or Steel plate ground | ||||
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 |
| Table size (mm) | 3000*2000 | 4500*2200 | 5000*2200 | 5500*2300 | 6000*2300 |
| Height of the whole cart (mm) | 450 | 600 | 650 | 700 | 700 |
| Wheel base (mm) | 1500 | 1700 | 1700 | 1800 | 1800 |
| Axles distance (mm) | 2500 | 3900 | 4300 | 4800 | 5200 |
| Turning radius (mm) | 2501 | 3901 | 4301 | 4801 | 5201 |
| Turning type | Turning while driving with no stop | ||||
| Control method for turning | Control button | ||||
| Turning structure | Mechanical | ||||
| Motor power (KW) | 3.5 | 7 | 10 | 12 | 15 |
| Wheel diameter (mm) | 300 (4) | 400 (4) | 400 (6) | 500 (6) | 500 (6) |
| Wheel material | ZG55+hydropurture | ||||
| Running speed (m/min) | 0-15 | 0-12 | |||
| Brake principle | Electric magnetic brake | ||||
| Ground balance | mechanical automatic adjustment | ||||
| Operation method | With wire or no wire | ||||
| Battery model | D-250 24pieces | D-440 24pieces | D-250 36pieces | D-330 36pieces | D-440 36pieces |
| Battery maintenance | Free of maintenance | ||||
| Charger's installation | Installed on cart | Split-type | |||
| Cart color | Yellow and warning sign | ||||
| Charger's function | Automatic stop for obstacles | ||||
| Radar control | 3-0.3 m, Automatic stop for obstacles | ||||
| Warning equipment | Sound and light | ||||
| Other functions | Turning light, night light and power display | ||||
The body of the cart is packed with tarp, the small parts will be packed with wooden cases. According the table size and quantity, the cart would be carefully fixed and transported by FCL, LCL, Bulk Transportation, Open Top Container, Flat Rack Container and so on.
