Product Details:
Payment & Shipping Terms:
|
| Powered Source: | Lead-acid Battery (Optional) | Operation Mode: | Pandent And Remote Controller |
|---|---|---|---|
| Cart Frame: | Q235B | Rail Gauge: | 1435mm (Customized) |
| Color: | Orange/Yellow/Blue/Customized | Running Distance: | No Limited |
| Wheel Type: | Polyurethane Coated Wheels | Safrty Device: | Buffer, Alarm Light, Emergency Stop Buttons |
| Special Function: | Anti-Explosion, Heat-Resistant, Lifting, Dumpling | Dimension: | Customized |
| High Light: | electric transfer cart,load transfer trolley |
||
Our technology team always puts innovating on the first place, continuously develop new material handling equipment products according to the market demand and customer's demand. They bravely face the technology challenge and overcome the technology difficulty together one and another.
1) Functions:
The main function of the material handling equipment is to transfer material from one place to another within a workshop or among workshops.
2) Working principle
This kind material handling equipments are powered by storage battery. Storage battery supplies power to DC traction motor, and the DC traction motor drives the carts.
3) Advantages
Having at least 2 omni-directional wheels;
Running flexibly and stably;
Running on cement ground or steel sheet ground, don't need rails;
The working time is unlimited by preparatory lead-acid battery;
The load capacity of the handling equipment is up to 300 tons;
How to choose a suitable material handling equipment?If you are interested in our product, please tell us the load capacity, speed, and running distance. We will give you an reasonable scheme. Thank you!
| Technial Parameters for Material Handling Equipment | |
| Rated Load(t) | 40 |
| Impacted rated load(t) | 60 |
| structure of frame | steel plates welded beam structure |
| Thickness of the steel plate | 16 |
| Cart weight ( t ) | 10 |
| Max.Wheel load ( t ) | 10 |
| Ground requirement | cement ground/steel plate ground |
| Table size ( mm ) | 5500x2300 |
| Height of the whole cart(mm) | 700 |
| Space from the ground ( mm ) | 50 |
| Wheels distance | 1800 |
| Axles distance | 4800 |
| Turning radius ( mm ) | 4801 |
| Turning type | turning while driving without stop |
| Control method for turning | control button |
| Turning structure | mechanical |
| Wheel diameter | 500/6 |
| Wheel quality | polyurethane wheels |
| Running speed ( m/min ) | 0-25 |
| Brake principle | electric magnetic force |
| Operation method | with wire or no wire |
| Charger motor's installation | installed on cart |
| Function of charger motor | automatic charging |
| Warning equipment | sound and light lamp |
