Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation

Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation
Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation

Large Image :  Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation

Product Details:
Place of Origin: Henan china
Brand Name: Portable Lifting Platform
Certification: CE ISO SGS
Model Number: Portable Lifting Platform
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD3000-6000/SET
Packaging Details: Trap and wooden case
Delivery Time: 20 work days after received balance payment
Payment Terms: L/C, T/T
Supply Ability: 30sets/week
Detailed Product Description
Type: Portable Lifting Platform Product Name: Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car For Material Transportation
Wheels Base(mm): 1500-1800 Ground Requirement: Cement Floor
Wheel Diameter(mm): 600 Ground Clearance(mm): 50
Motor Power(Kw): 3.5-20 Running Speed(m/min): 0-20
High Light:

hydraulic platform lift

,

outdoor lifting platform

Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation



The Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation can be customizd.The Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation can be a good solution for the heavy load factory material transportation form one place to another.The Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation achived the automatic cargo loading and unloading.



Advantages

1.Runs flexibly on the cemment floor.

2.Smooth lifting and high synchronism

3.Adding PLC,the program is better,the performance is stronger

4.Equipped unique design of hybrid power

5.Speed of lifting is stable and adjustable

6.Automatic warehouse transportation

7.Convenient for the transportation of factory materials

8.No limitation of the ascending and descending times number

9.The lifting height can be customized according to your requirement.



Product parameter

Model BXC-2t BXC-20t BXC-50t BXC-100t BXC-150t
Rated Load(t) 2 20 50 100 150
Table Size(mm) Length(L) 2000 4000 5500 6500 10000
  Width(W) 1500 2200 2500 2800 3000
  Heigth(H) 450 550 650 900 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 2000 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 1 2.2 5 10 15
Battery Capacity(Ah) 180 180 330 440 600
Battery Voltage(V) 24 48 48 72 72
Running Time When Full Load 4.32 4 3.3 3.2 2.9
Running Distance for One Charge(Km) 6.5 4.8 4 3.8 3.2
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Reference Weight(t) 2.8 5.9 8 14.6 26.8
Recommended Rail Model P15 P24 P43 QU100 QU100



The scheme

Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation



Application

The Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation can be a good choice for the steel pipe, iron, scrap, scrap metal material waste transportation.

Hydraulic Portable Lifting Platform Carbon Steel Plate Electric Transfer Car for Material Transportation
