40T Battery Powered Industrial Transfer Car For Heavy Material Transportation

China 40T Battery Powered Industrial Transfer Car For Heavy Material Transportation supplier
40T Battery Powered Industrial Transfer Car For Heavy Material Transportation supplier 40T Battery Powered Industrial Transfer Car For Heavy Material Transportation supplier 40T Battery Powered Industrial Transfer Car For Heavy Material Transportation supplier 40T Battery Powered Industrial Transfer Car For Heavy Material Transportation supplier

Large Image :  40T Battery Powered Industrial Transfer Car For Heavy Material Transportation

Product Details:

Place of Origin: Henan, China(mainland)
Brand Name: Perfte
Certification: CE, ISO, SGS
Model Number: Transfer car

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: $5500-$8000
Packaging Details: wooden case
Delivery Time: 5-7 work days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 60 set per month
Contact Now
Detailed Product Description
Type: Transfer Car Warranty: 24 Month Long Guarantee
Capacity: Customized Power Supply: Battery
Running Speed: 0-18m/min Product Name: 40T Battery Powered Industrial Trackless Trolleys For Heavy Material Transportation
Motor Power: 6 Kw

40T Battery Powered Industrial Transfer Car For Heavy Material Transportation





Description



This series of 40T Battery Powered Industrial Trackless Trolleys for Heavy Material Transportation can be towed adopt box girder structure, which has the advantages of strong bearing capacity, no distortion, stable start, large starting moment, small impact on reducer, low voltage, long service life, unlimited running distance, and low requirement for track laying. Compared with KPJ, KPD, KPC and KPT series trackless factory flat transfer carts,40T Battery Powered Industrial Trackless Trolleys for Heavy Material Transportation can has more safety and motor flexibility. 40T Battery Powered Industrial Trackless Trolleys for Heavy Material Transportation is suitable for the occasions of low frequency and medium and long distance transportation.

40T Battery Powered Industrial Trackless Trolleys for Heavy Material Transportation


Functions of 40t Battery powered transfer Trackless flat cart:

  • Payload from 1 ton to 100 tons;
  • With lifting holes, convenient to shipment;
  • Anti-explosion,Anti-high temperature;
  • Fixed speed or variable speed capabilities;
  • On board charging is available if battery drives;
  • Strong bearing capacity
  • 360 degree rotate
  • No limitance of running distance and running routine
  • Battery powered,maintance-free supply mode



Product parameters

Model BWP-5t BWP-20t BWP-30t BWP-40t BWP-50t
Rated Load(t) 5 20 30 40 50
Impacted rated load(t) 7.5 30 45 60 75
Structure of Frame Steel plates welded, beam
thickness of the steel plate 8 14 14 16 16
Cart weight(t) 4.3 7.9 8.8 10 10.5
Max. wheel load (t) 2.8 5.6 7.7 10 12
Ground requirement Cement floor or Steel plate ground
Ground Clearance(mm) 50 50 50 50 50
Table size (mm) 3000 X 2000 4500 X 2200 5000 X 2200 5500 X 2300 6000 X 2300
Height of the whole cart (mm) 450 600 650 700 700
Wheel base (mm) 1500 1700 1700 1800 1800
Axles distance (mm) 2500 3900 4300 4800 5200
Turning radius (mm) 2501 3901 4301 4801 5201
Turning type Turning while driving with no stop
Control method for turning Control button
Turning structure Mechanical
Motor power (KW) 3.5 7 10 12 15
Wheel diameter (mm) 300 (4) 400 (4) 400 (6) 500 (6) 500 (6)
Wheel material ZG55+hydropurture
Running speed (m/min) 0-15 0-12
Brake principle Electric magnetic brake
Ground balance Mechanical automatic adjustment
Operation method With wire or no wire
Battery model D-250 24pieces D-440 24pieces D-250 36pieces D-330 36pieces D-440 36pieces
Battery maintainance Free of maintainance
Charger's installation Installed on cart Split-type
Cart color Yellow and warning sign
Charger's function Automatic stop for obstacles
Radar control 3-0.3 m, Automatic stop for obstacles
Warning equipment Sound and light
Other functions Turning light, night light and power display


Application
40T Battery Powered Industrial Trackless Trolleys for Heavy Material Transportation

After-sales

  • Our commitment: The load bearing safety factor of the trackless car is no less than 120%.
  • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
  • 16 hours engineering service and 24 hours internet service for our customers.
  • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
  • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
