Steering 30t Customization Electric Transfer Cart Table Factory Use

Steering 30t Customization Electric Transfer Cart Table Factory Use
Steering 30t Customization Electric Transfer Cart Table Factory Use Steering 30t Customization Electric Transfer Cart Table Factory Use Steering 30t Customization Electric Transfer Cart Table Factory Use Steering 30t Customization Electric Transfer Cart Table Factory Use

Large Image :  Steering 30t Customization Electric Transfer Cart Table Factory Use

Product Details:
Place of Origin: Henan China
Brand Name: ladle transfer cart on rails
Certification: CE ISO SGS
Model Number: ladle transfer cart on rails
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Usd2800-5000/set
Packaging Details: Trap and wooden case
Delivery Time: 20 work days after received balance payment
Payment Terms: L/C, T/T
Supply Ability: 30sets/week
Detailed Product Description
Type: Ladle Transfer Cart On Rails Product Name: Ladle Industrial Transfer Cart To Transfer Molten Steel And Can Be Equipped Hydraulic Lifting Equipment
Wheel Diameter(mm): 270-600 Rail Inner Gauge(mm): 1200-2000
Running Speed(min): 0-25 Motor Power(kw): 1-15
Running Time When Full Load: 2.9-4.32
High Light:

30t electric transfer cart

,

steering electric transfer cart

,

customization ladle transfer trolley



30t Customization Electric Steering Cart Table for Factory use



Descraptions

Henan Perfect Handling Equipment Co., Ltd. is specializing in the design and manufacture of heavy material transport system to solve every material handling requirement. Our product includes Industrial Trailers, Transfer Cars, Electric Railway Transfer Trolley, Battery Operated Transport Trolley, Coil and Pipes Carrier Equipment, Ladle Handling Equipment, Hydraulic Lift Table, Turntables and many other specialty items. Our line of cargo carrier are designed and manufactured to accommodate the needs of a wide range of industries including Steel, Aluminum, Automotive, Heavy Manufacturing and others. These material carriers are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

Steering 30t Customization Electric Transfer Cart Table Factory Use 0



Working for area



Steering 30t Customization Electric Transfer Cart Table Factory Use 1



Technical Table



Model 2t 20t 50t 100t 150t
Rated Load(t) 2 20 50 100 150
Table Size(mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Heigth(H) 450 550 650 900 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 2000 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 1 2.2 5 10 15
Running time When Full Load 4.32 4 3.3 3.2 2.9
Running Distance for Once Charge(KM) 6.5 4.8 4 3.8 3.2
Reference Weight(t) 2.8 5.9 8 14.6 26.8
Recommended Rail Model P15 P24 P43 QU100 QU100
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Battery Voltage(v) 24 48 48 72 72
Battery Capacity(Ah) 180 180 330 440 600



The Application


For horizontal load transfers of a wide range of material, we have the heavy duty, high quality cargo carrier solutions you need. Transfer carts are used: to carry loads along assembly lines; transfer material from one work station to the next; store and transport an entire shift worth of production. They can even be used as a stable yet moveable machine base. With different styles and standard capacities up to 300 tons, we have the solutions you need and each style can be designed for your specific application.



 ladle industrial transfer cart to transfer molten steel and can be equipped hydraulic lifting equipment



 ladle industrial transfer cart to transfer molten steel and can be equipped hydraulic lifting equipment
