Product Details:
Payment & Shipping Terms:
|
| Place Of Origin: | Henan, China (Mainland) | Product Name: | Heavy Capacity Motorized Trackless Transfer Cart |
|---|---|---|---|
| After-sales Service Provide: | Engineers Available To Service Machinery Overseas | Color: | Customized |
| Running Speed: | 20m/min | Table Size: | Customized |
| High Light: | electric transport cart 20m/min,SGS electric transport cart,5T electric transport cart |
||
5T No real Heavy duty Stone mine use Transport Electric battery car
DESCRAPTIONS
The 5T No real Heavy duty Stone mine use Transport Electric battery car is consisted of power source ,gear train ,steel structure bearing frame ,steering gear ,running gear control system and fault diagnosis module.All the cars are equipped with warnong alarm and secuity detection appartus,and the alarm would stop immediately if there was any obstacle or pedestrian in the running path of the car.Also,we will provide intelligent automatic rapid charger with the car.The PLC is also alterative if it's necessary.
| Model | BWP-5t | BWP-20t | BWP-30t | BWP-40t | BWP-50t |
| Rated Load(t) | 5 | 20 | 30 | 40 | 50 |
| Max. Wheel Load (t) | 2.8 | 5.6 | 7.7 | 10 | 12 |
| Ground Requirement | Cement floor or Steel plate ground | ||||
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 |
| Table Size (mm) | 3000 X 2000 | 4500 X 2200 | 5000 X 2200 | 5500 X 2300 | 6000 X 2300 |
| Height (mm) | 450 | 600 | 650 | 700 | 700 |
| Wheel Base (mm) | 1500 | 1700 | 1700 | 1800 | 1800 |
| Axles Distance (mm) | 2500 | 3900 | 4300 | 4800 | 5200 |
| Turning Radius (mm) | 2501 | 3901 | 4301 | 4801 | 5201 |
| Turning Structure | Mechanical | ||||
| Motor Power (KW) | 3.5 | 7 | 10 | 12 | 15 |
| Wheel Diameter (mm) | 300 (4) | 400 (4) | 400 (6) | 500 (6) | 500 (6) |
| Wheel Material | ZG55+hydropurture | ||||
| Running Speed (m/min) | 0-15 | 0-12 | |||
| Brake Principle | Electric magnetic brake | ||||
| Operation Method | Raido Remote Control | ||||
| Battery Maintainance | Free of maintainance | ||||
| Charger's Installation | Installed on cart | Split-type | |||
| Cart Color | Customized | ||||
| Charger's Function | Automatically cut off the power when the battery is fully charged | ||||
| Radar Control | 3-0.3 m, Automatic stop for obstacles | ||||
| Warning Equipment | Horn and Flash Light | ||||
| Other Functions | Turning light, night light and power display | ||||
FAQ:
1. Q: What is the size and load of this Transfer Car?
A:The size and load of our this transfer car is customized design according to your requirement.
2. Q: How do you transport the Transfer Car and what is the package ?
A: For the big part, we will pack thetransfer car with tarpaulin and wood pallet on the bottom of the rail coil transfer car to prevent it from moving. For the small part, we will pack it in wood case.
3. Q: What is the leading time, delivery term, and payment term?
A: Usually our leading time is 45 days, for some special rail coil transfer car, such as rail coil transfer car, it maybe longer to 60 days. About the delivery term, we accept EXW, FOB, CIF, DDU. About the payment, we accept T/T or L/C.
4. Q: What is your MOQ?
A: At present, our MOQ is 1 set.
