Electric Material Battery Power SGS Heavy Duty Transfer Cart

Electric Material Battery Power SGS Heavy Duty Transfer Cart
Electric Material Battery Power SGS Heavy Duty Transfer Cart Electric Material Battery Power SGS Heavy Duty Transfer Cart Electric Material Battery Power SGS Heavy Duty Transfer Cart Electric Material Battery Power SGS Heavy Duty Transfer Cart Electric Material Battery Power SGS Heavy Duty Transfer Cart

Large Image :  Electric Material Battery Power SGS Heavy Duty Transfer Cart

Product Details:
Place of Origin: Henan China
Brand Name: Perfte
Certification: CE ISO SGS
Model Number: Material Transfer Cart
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Usd4800-7000/set
Packaging Details: Trap and wooden case
Delivery Time: 30 work days after received balance payment
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 40 sets/week
Detailed Product Description
Product Name: 20t Battery Powered Material Transfer Cart Running On Cement Floor Wheel Diameter(mm): 250-500
Ground Clearance(mm): 50-80 Wheel Quantity: 4
Running Speed(m/min): 0-20 Type: Rail Transfer Car
High Light:

flatbed heavy duty transfer cart

,

sgs heavy duty transfer cart

,

flatbed heavy duty transfer car

Factory use Electric Heavy Duty Material Battery Power Transfer Cart





Descraptions



The Material Transfer Cart is battery powered and the material transfer cart is widely used in factory workshop.For the trackless transfer cart, It’s easy to turn 360 degrees at a minimum turning radius. The operation ways are hand held push button and remote control, the steering wheel sets coordinate with die wheel sets to carry the loads on the customized platform.



Electric Material Battery Power SGS Heavy Duty Transfer Cart 0



Product parameters



Moldel BWP-5T BWP-10T BWP-25T BWP-40T BWP-65T BWP-100T
Length(mm) 2000 3600 4500 5000 5600 6000
Width(mm) 1500 2000 2200 2500 2500 2600
Height(mm) 450 500 600 650 700 800
Wheel Diameter(mm) 270 300 400 500 600 600
Ground Clearance (mm) 50 50 50 50 75 75
Motor Power(Kw) 1 1.6 2.2 4 6.3 8/10
Running Speed(m/min) 0-30 0-25 0-20 0-20 0-20 0-20
Max Wheel Load(KN) 14.4 42.6 77.7 142.8 221.4 343.8
Battery Capacity (Ah) 180 160 250 330 400 600
Battery Voltage(V) 24 48 48 48 48 72
Running time when full load(h) 4.5 4.8 4 3.5 3.3 3





Production Process of DC Powered Rail Transfer Wagon


CNC Cutting
The steel plate is transported from warehouse to CNC cutting workshop for cutting.
Preliminary Assembling
Workers put the cut steel plate together according to the design drawing.
Welding
Weld the steel plate with automatic welding machine after the preliminary assembling.
Post weld treatmen
Test the welding section after the welding, polish and burring. Post weld treatment to eliminate welding stress.
Spray Primer
Transport the structure part after processing to painting booth for spraying primer. The main component of the primer is zinc rich epoxy antirust paint.
Assembling
Assemble the structure parts after spraying primer with wheels, motors and gear box, etc.

Paint finish
Transport the assembled cart to painting booth, inspect the integrity of primer. After that paint the finish
.
Debugging
Debugging the cart after painting the finish with electric control system, after the debugging, the cart will
be tested without load and then with load. After the inspection, the cart will be transported to storage area.

Electric Material Battery Power SGS Heavy Duty Transfer Cart 1



Details of Battery Powered Material Transfer Cart



20t Battery Powered Material Transfer Cart Running on Cement Floor



Our Company
We have been specializing in rail flat cart manufacture for over 15 years. With advanced equipment, excellent engineers and professional workers, we have got the certificates of CE, SGS, ISO. Our products can be used in industrial, steel, pharmacy, mining and many other lines. So we can assure that we will provide high quality and cost-effective products for you!
