Product Details:
Payment & Shipping Terms:
|
| Product Name: | Metallurgy Factory Track Electric Transfer Cart | Capacity: | 1-300T |
|---|---|---|---|
| Table Size: | Customized | Height: | Customized |
| Running Speed: | 0-50/min(Adjustable) | Special Function: | Anti-Explosion, Heat-Resistant, Lifting, Dumpling |
| Warranty: | 12 Months | ||
| High Light: | metallurgy heavy duty transfer cart,remote control heavy duty transfer cart,metallurgy remote control transfer car |
||
Introduction about transfer cart
The carts that run on the shop floor level. Transfer carts come in many sizes, styles and capacities designed to suit your operations specific needs. They are modular in construction and allow movement changes at ground level in all types of industries and applications. The transfer carts on rails or straight shifts can either be powered by batteries or cable reels. Whereas the directional also named free movement transfer carts are bettery available as battery powered.
We provide various of transfer cart, transfer trolley, railway transfer cart, car turntable, coil cart, die car, ladle transfer car, heavy duty transpotor, scissor lifting transfer car and so on. We supply OEM service for you. We have rich experience in manufacturing transfer cart. We dedicate ourselves to manufacture and supply of transfer trolley with nice service. We are looking forward to your E-mail and establishing cooperative relationship with you!
| Model | BDGZ-2t | BDGZ-20t | BDGZ-50t | BDGZ-100t | BDGZ-150t | |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
| Table Size(mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 | |
| Heigth(H) | 450 | 550 | 650 | 850 | 1200 | |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 | |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 0.8 | 2.5 | 5.5 | 11 | 15 | |
| Transformer Power(KVA) | 3 | 6.8 | 10 | 30 | 30 | |
| Transformer Quanity | 1 | 1 | 1 | 1 | 1 | |
| Running Distance(m) | 70 | 70 | 50 | 50 | 50 | |
| Max Wheel Load(KN) | 14.4 | 77.7 | 174 | 343.8 | 265.2 | |
| Reference Weight(t) | 2.8 | 5.9 | 8 | 14.6 | 26.8 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 | |
