Product Details:
Payment & Shipping Terms:
|
| Powered Source: | Conductor Rail | Operation Mode: | Pandent And Remote Controller |
|---|---|---|---|
| Cart Frame: | Q235B | Rail Gauge: | 1435mm (Customized) |
| Color: | Yellow And Blue/Customized | Working Time: | Whole Day |
| Wheel Type: | Cast Steel Wheel | Safrty Device: | Buffer, Alarm Light, Emergency Stop Buttons |
| Special Function: | Anti-Explosion, Heat-Resistant, Lifting, Dumpling | Dimension: | Customized |
| High Light: | ISO Automated Material Transfer Cart,Q235B Steel Material Transfer Cart,1435mm Automated Rail Handling Cart |
||
Product Introduction
Our line of Low Voltage Products Transfer Car is designed to accommodate the needs of a wide range of industries such as steel, aluminum, automotive, stamping, heavy manufacturing and several others. These units are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.
Application Sites
For horizontal load transfers of a wide range of material, we have the heavy duty, high quality Products Transfer Car solutions you need. They are used: to carry loads along assembly lines; transfer material from one work station to the next; store and transport an entire shift worth of production. Products Transfer Car can even be used as a stable yet moveable machine base. With four different styles and standard capacities up to 60 tons, we have the solution you need and each style can be designed for your specific application.
Steel Mill & Coil Plant
The rail push transfer car can be applied in steel mill to handling steel pipes and coils and it can lift up or put down the coils freely with hydraulic lifting table. And the V- frame can be added on the deck to prevent the coils falling down. To ensure safety, the rail push transfer cart can be operated by the wireless control. We can make a suitable V-frame to you according to the coil dimension, coil weight, etc.
Warehouse & Logistics
The rail push transfer cart can be used to transfer heavy material from one warehouse to another or from warehouse to factory. For example, it can transfer paper coils in paper mill and transfer large package to another place. Due to it can travel in all kinds of rails with automatically operate, it can greatly improve the working efficiency.
Petroleum industry
With influence of the length on oil pump and sucker rods, the table size of the rail push transfer cart is large than common cart. With box girder structure, it cannot deformation with large load capacity. It can applied in all kinds of conditions, and mainly used to transfer oil pump, parts and finished products between workshops.
Customizations
Transfer Cart: Rail transfer cart, Trackless transfer car, Battery operated transport trolley, Coils cart, Ladle transfer cart, Hydraulic scissors lift table cart etc.
Industrial Trailer: Flatbed trailer, Factory trailer, Utility trailer, Workshop transfer trailer, Airport baggage cargo trailer, Car transport trailer, Motorized transfer trailer etc.
Cargo Transportation: Die cart, Coils transport cart, pipes transfer carriage, steel beam transporter, aluminum plate transport vehicle, transformer carrier bogie
Speical Handling Equipment: Ladle transfer trolley, Ferry Transfer wagon, Cross-rail transport equipmet, Motorized turntable, Vacuum furnace transfer cart, Automatic vehicle etc.
Technical Parameters
| BDGZ SERIES TRANSFER CART TECHNIAL PARAMETER TABLE | |||||
| Model | BDGZ-2t | BDGZ-16t | BDGZ-30t | BDGZ-50t | |
| Rated Load(t) | 2 | 16 | 30 | 50 | |
| Table Size (mm) | Length(L) | 2000 | 4000 | 4500 | 5500 |
| Width(W) | 1500 | 2000 | 2200 | 2500 | |
| Height(H) | 450 | 500 | 600 | 650 | |
| Wheel Base(mm) | 1200 | 2800 | 3200 | 4200 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 1435 | |
| Wheel Diameter(mm) | 270 | 350 | 400 | 500 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | |
| Motor Power(kw) | 1 | 2 | 3.5 | 5 | |
| Transformer Power(KVA) | 3 | 6.8 | 10 | 20 | |
| Transformer Quantity | 1 | 1 | 1 | 1 | |
| Running Distance(m) | 70 | 70 | 70 | 50 | |
| Max Wheel Load(KN) | 14.4 | 64.5 | 174 | 343.8 | |
| Reference Weight(t) | 2.8 | 5.5 | 8 | 14.6 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | |
Packing & Shipping
The length of the transfer car is less than 6m while the width is less than 2.2m it will be transported by 20ft container.
If the length of the transfer car is longer than 5.9m and less than 12m, it will be transported by 40ft container. If the quantity is 2 sets or 3 sets, they can be transported by full container. If the quantity is 1 set, it can be transported by LCL Container.
If the length of the transfer car is less than 12m, the width is beyond 2.2m. It needs to be transfer by flat rack (20 or 40 ft). If the equipment is beyond above dimension, and quantity need to consider bulk cargo.
