Product Details:
Payment & Shipping Terms:
|
| Year: | 2017 | Type: | Hydraulic Lifting |
|---|---|---|---|
| Condition: | New | Color: | Yellow, Customized |
| Wheel Quantity: | 4 | Power: | Storage Battery |
| Safety Device: | Alarm Light, Buffer, Radar Detector | Lifting Height: | Customized |
| Brake: | Electromagnetic Brake | Wheel: | PU Wheel |
| High Light: | portable platform lift,outdoor lifting platform |
||
Flexible Scissor Hydraulic Portable Lifting Platform for Cargo Transportation
Product Preview of Flexible Lifting Platform
Our lifting platform is very flexible and stable to operate. The platform table size, lifting height and load capacity are both customized. We can produce special products as per your special requirments. It's powered by storage battery and has no limitation of running distance and lifting time. Two platforms can work at the same time. It's a cost saving and convenient transportation method for you!
Using Sites of Scissor Hydraulic Lifting Platform
Our lifting carts are wildly used in many different lines and sites. For example, you can use it to transfer coil materials in the factory, trasport cargo in the airport, load containers in the wharf and used in the construction. All in all, we can provide all kinds of transfer carts for you according to your using environments.
Parameters of Scissor Hydraulic Lifting Platform
| Model | BXC-2t | BXC-20t | BXC-50t | BXC-100t | BXC-150t | |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
| Table Size (mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 | |
| Height(H) | 450 | 550 | 650 | 900 | 1200 | |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 200 | 2000 | |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 1 | 2.2 | 5 | 10 | 15 | |
| Battery Capacity | 180 | 180 | 330 | 440 | 600 | |
| Battery Voltage | 24 | 48 | 48 | 72 | 72 | |
| Running Time When Full Load | 4.32 | 4 | 3.3 | 3.2 | 2.9 | |
| Running Distance for One Charge(Km) | 6.5 | 4.8 | 4 | 3.8 | 3.2 | |
| Max Wheel Load(KN) | 14.4 | 77.7 | 174 | 343.8 | 265.2 | |
| Reference Weight(t) | 2.8 | 5.9 | 8 | 14.6 | 26.8 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 | |
Sales Service
Our guarantee period is 12 months, after making sure the product is working well. During this period, we can repair, change the machine for you freely. After this period, we only charge cost price for you. We can also help you to fit, adjust the equipment till they work normally. We are striving for high quality for you all the way!
