Product Details:
Payment & Shipping Terms:
|
| Load Capacity: | 20t/Customized | Operation Mode: | Pandent And Remote Controller |
|---|---|---|---|
| Cart Frame: | Q235B | Rail Gauge: | 1435mm (Customized) |
| Color: | Yellow/Customized | Working Time: | 6-8 Hours |
| Wheel Type: | Cast Steel Wheel | Safrty Device: | Buffer, Alarm Light, Emergency Stop Buttons |
| Special Function: | Anti-Explosion, Heat-Resistant, Lifting, Dumpling | Dimension: | Customized |
| High Light: | Explosion Proof Metallurgy Rail Cart,Electrical Cargo Metallurgy Rail Cart,50T Load Pallet Transfer Carts |
||
Product Introduction
Our line of electrical cargo trailers are designed to accommodate the needs of a wide range of industries such as steel, aluminum, automotive, stamping, heavy manufacturing and several others. There are several choices of power types you can choose.The transfer cart can be powered by battery,busbar,cable drum,trailing cable or powered by rail.We will give our proposal according to your workspace.If this type of transfer cart is not suitable for you,we also can design a special one to meet all of your need.These units are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.
How to Choose cart
There are types transfer carts, each designed for different applications. They are:
Towed Type Carts - For loads up to 60 ton. Carts have casters or crane wheels and are manually moved on smooth to semi-smooth floors or are towed behind lift trucks or behind powered carts mounted on rail. They are an economical alternative to purchasing a second powered cart. Winches can also be used to pull carts of this type for on-rail applications. Carts can be sized according to requirements of work areas with space constraints.
On-Rail Type Carts - For loads up to 100 ton. Carts are mounted on steel rail for shuttling along a fixed path. They can be AC powered or DC battery powered. Typically used for moving materials such as steel or tanks of liquids from one location to another. Larger cart capacities and sizes are available for specific applications. Custom deck frames can be designed for specific assemblies to carry an entire shift of production and even serve as a stable moveable machine base.
Steerable Type Carts - For loads up to 45 ton. Carts have two fixed and two swivel casters and are DC battery powered (optional AC powered). Carts are designed to travel on smooth to semi-smooth level floors. Customization is available for specific applications.
Descraption picture
Parameter Table---Battery Powered Transfer Trolley
| Product Name | Model | Power Supply Mode | Load Capacity | Running distance | Usage |
| Rail Transfer Cart | BDG | Conductor Rail | We can design 1-300t load transfer cart. The load capacity and table size is customized according to the working condition and the client's requirements. | ≤70m | Handling industrial materials and heavy duty equipment, such as steel plate, steel tube, steel ladle, steel pipe, coils, roller, die mold, precast slab, oil and gas, scrap bucket, bricks, boiler, etc. |
| Battery Powered Transfer Car | BXC | Battery | Unlimited | ||
| Cable powered Transfer Trolley | BJT | Cable Drum | ≤50m | ||
| Electric Transfer Cart | BTL | Trailing Cable | ≤20m | ||
| Busbar Powered Handling Vehicle | BHX | Busbar | Unlimited | ||
| Towed Rail Trailer | BP | Towed by other machine | Unlimited | ||
| Industrial Trailer | BWT | Manually or towed by forklift or other machine | 1-150t on cement or steel floor. | Unlimited | |
| Trackless Handling Wagon | BWP | Battery | Unlimited |
