30 Ton Carbon Steel Battery Operated Transfer Trolley Material Handling

30 Ton Carbon Steel Battery Operated Transfer Trolley Material Handling
30 Ton Carbon Steel Battery Operated Transfer Trolley Material Handling 30 Ton Carbon Steel Battery Operated Transfer Trolley Material Handling 30 Ton Carbon Steel Battery Operated Transfer Trolley Material Handling 30 Ton Carbon Steel Battery Operated Transfer Trolley Material Handling

Large Image :  30 Ton Carbon Steel Battery Operated Transfer Trolley Material Handling

Product Details:
Place of Origin: Henan China
Brand Name: Coil Transfer Car
Certification: CE ISO SGS
Model Number: Coil Transfer Car
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD3000-6000/set
Packaging Details: Trap and wooden case
Delivery Time: 20 work days after received balance payment
Payment Terms: L/C, T/T
Supply Ability: 30sets/week
Detailed Product Description
Product Name: 50 Ton Carbon Steel Coil Transfer Car Battery Powered For Aluminum Coil Transportation Running Speed(m/min): 0-25
Motor Power(Kw): 0.8-15 Wheel Quantity: 4
Wheel Base(mm): 1200-7000 Wheel Diameter(mm): 270-600
Ground Clearance(mm): 50
High Light:

carbon steel battery operated transfer trolley

,

battery operated transfer trolley material handling

,

30 ton battery transfer trolley



30t Ton Carbon Steel Coil Material Handling Car Battery Powered



Introduction of products



PERFECT Coil Transfer Cart are used to transport steel coils and pipes for metal industry. This Coil Transfer Cart are designed to be an extremely cost effective, safe and flexible load moving alternative.
The Transfer Carts are manual guide vehicles equipped with specialized drive systems which make it possible to easily, precisely and safely move up to 200 tons. The coil heavy load transfer cart is sometimes called a heavy transporter, headless transporter or self-propelled modular transporter.



30 Ton Carbon Steel Battery Operated Transfer Trolley Material Handling 0


Advantages
1. Powered by battery,cable and low-voltage track.
2. No harm to the cemment ground.
3. Can add  V-shaped and drum protection coils from falling from cross transport.
4. No environmental limitation.
5. The V/U frame can be take apart optional.
6. Remote control and button suspension are available.
7. The safety devices such as buffers,proximity switches, acousto-optic alarms,etc have been employed.

8. The table size and capacity can be customized.



Technical table



Model BXC-2t BXC-20t BXC-50t BXC-100t BXC-150t
Rated Load(t) 2 20 50 100 150
Table Size(mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Heigth(H) 450 550 650 900 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 2000 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 1 2.2 5 10 15
Battery Capacity 180 180 330 440 600
Battery Voltage 24 48 48 72 72
Running Time When Full Load 4.32 4 3.3 3.2 2.9
Running Distance for One Charge(Km) 6.5 4.8 4 3.8 3.2
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Reference Weight(t) 2.8 5.9 8 14.6 26.8
Recommended Rail Model P15 P24 P43 QU100 QU100



Application



Coil Transfer Cart:
For horizontal load transfers of a wide range of material, we have the heavy duty, high quality Transfer Cart solution you need. Transfer carts are used: to carry loads along assembly lines; transfer material from one work station to the next; store and transport an entire shift worth of production. They can even be used as a stable yet moveable machine base. With four different styles and standard capacities up to 60 tons, we have the solution you need and each style can be designed for your specific application.
