10 Ton Capacity Battery Powered Cart On Rails For Heavy Cargo Handling

10 Ton Capacity Battery Powered Cart On Rails For Heavy Cargo Handling
10 Ton Capacity Battery Powered Cart On Rails For Heavy Cargo Handling 10 Ton Capacity Battery Powered Cart On Rails For Heavy Cargo Handling 10 Ton Capacity Battery Powered Cart On Rails For Heavy Cargo Handling 10 Ton Capacity Battery Powered Cart On Rails For Heavy Cargo Handling

Large Image :  10 Ton Capacity Battery Powered Cart On Rails For Heavy Cargo Handling

Product Details:
Place of Origin: China(Mainland)
Brand Name: 10 ton capacity battery powered transfer vehicle on rails
Certification: CE ISO SGS
Model Number: 10 ton capacity battery powered transfer vehicle on rails
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 1000~8000 SET
Packaging Details: trap and wooden case
Delivery Time: 20 work days after received balance payment
Supply Ability: 100 sets month
Detailed Product Description
Product Name: Battery Powered Transfer Vehicle On Rails Load Capacity: 1-300T
Table Size: Customized Height: Customized
Running Speed: 0-50/min(Adjustable) Color: Customized
After-sales Service Provided: Engineers Available To Service Machinery
High Light:

die handling equipment

,

powered trolley cart

,

SGS Battery Powered Cart



10 Ton Capacity Battery Powered Cart On Rails For Heavy Cargo Handling




This 10 ton capacity battery powered transfer vehicle on rails is usually used at ship yard, plant and factory, certain production line. The 10 ton capacity battery powered transfer vehicle on rails could get power from outside or from the battery. The 10 ton capacity battery powered transfer vehicle on rails was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and/or products through manufacturing facilities.The 10 ton capacity battery powered transfer vehicle on rails construction is based on our world renowned die transport vehicles and provides controlled movement of heavy and oversized loads such as dies, coils and work in progress. Our 10 ton capacity battery powered transfer vehicle on rails is available in a number of configurations specifically designed to suit the needs of our customers.

Customer use site map

battery powered transport vehicle

Technical Parameter of transport vehicle
Model BXC-2t BXC-20t BXC-50t BXC-100t BXC-150t
Rated Load(t) 2 20 50 100 150
Table Size(mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Heigth(H) 450 550 650 900 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 2000 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 1 2.2 5 10 15
Battery Capacity 180 180 330 440 600
Battery Voltage 24 48 48 72 72
Running time When Full Load 4.32 4 3.3 3.2 2.9
Running Distance for Once Charge(KM) 6.5 4.8 4 3.8 3.2
Reference Weight(t) 2.8 5.9 8 14.6 26.8
Recommended Rail Model P15 P24 P43 QU100 QU100

NOTES:

  • Flat deck or fixtures for transporting special payload;
  • Custom deck configurations may include lift, tilt, or rotate function;
  • Payload from 1 ton to 300 tons;
  • Fixed speed or variable speed capabilities;
  • On board charging is available if battery drives;
  • With forward or backing driving;
  • Options for automatic control;
  • Available safety equipment includes horn, lights, emergency stop, bumpers and detector.



Application Sites of battery powered transfer vehicle on rails

The 50 ton capacity battery powered transfer vehicle on rails
